Expanded PTFE Joint Sealant



TFCO expanded PTFE joint sealant is a soft, compressible gasket material made of 100% pure, expanded PTFE. It is a form-in-place gasket that conforms to almost any sealing surface. Upon compression, it forms a thin, hard ribbon that fills in surface irregularities and creates an extremely tight seal. It is capable of withstanding a wider range of pressures, temperatures and chemical environments than any other soft gasket.

Our joint sealant can be used in just about any accessible bolted joint that features a flat or serrated sealing surface. It is also easy to install and remove, making it a highly versatile and cost-effective solution for many demanding sealing applications.




Sizes/Part Numbers (custom lengths available)

 1/8" x 50'
 JS020050
               1/8" x 100'
JS020100
               1/8" x 500'
JS020500
  3/16" x 75'
 JS030075
       3/16" x 150'
JS030150
       3/16" x 750'
JS030750
1/4" x 50'
JS040050
       1/4" x 100'
JS040100
       1/4" x 500'
JS040500
 3/8" x 25'
JS060025
      3/8" x 50'
JS060050
      3/8" x 250'
JS060250
 1/2" x 15'
JS080015
       1/2" x 30'
JS080030
       1/2" x 150'
JS080150
 5/8" x 15'
JS100015
       5/8" x 30'
JS100030
       5/8" x 150'
JS100150
 3/4" x 15'
JS120015
       3/4" x 30'
JS120030
       3/4" x 100'
JS120100
 1" x 15'
JS160015
       1" x 30'
 JS160030
       1" x 75'
 JS160075
Specifications

Temperature Range: -450 deg F to 525 deg F continuous
-450 deg F to 600 deg F intermittent
Pressure Range: Full Vacuum to 3,000 psi
pH Range: 0-14
Pressure (psi) x Temp (deg F): 350,000
FDA Compliant: PTFE to 21 CFR 177.1550
Adhesive to 21 CFR 175.105
ASTM Testing: F36 Compressibility 64-69%
F38 Creep Resistance 38-40%
